Disconnect the battery to avoid accidental sparks during installation.

Mount the Ignition System

• Locate the exhaust pipe(s) and clean the area where the ignition system will be mounted.

• Attach the spark plug(s) securely near the exhaust tip using the provided hardware.

Install the Flame Module

• Choose a safe, dry location to mount the flame module.

• Secure it using screws or adhesive, ensuring it won’t shift while driving.

Connect the Wiring

• Run the wiring harness from the flame module to the engine bay and locate your ignition power supply wire for your coil packs (find the ignition fuse and follow the wire to a safe place to splice).

• Use zip ties to secure the wiring along the chassis to keep it away from hot or moving parts.

• Connect the wires as per the instructions.

Install the Switch

• Mount the activation switch in an easily accessible location, such as the dashboard or center console.

• Run the wiring from the switch to the flame module, following the instructions.

• Reconnect the battery.

• Ensure all connections are secure and insulated to prevent short circuits.

Test the System

• Double-check all connections and ensure there are no loose wires or fuel leaks.

• Start the car and turn on the flame kit switch to test the system. Adjust if needed. When the button is pressed with the car in accessories mode the spark plugs will spark.

Secure Everything

• Ensure all components are tightly secured and safe from heat or movement while driving.

• Recheck all connections and clean up any exposed wiring.

Important Notes:

• Always follow the instructions provided and do your research, as installation may vary depending on your vehicle.

• Test in a safe, open area away from flammable materials.
